| ► IP-Link 1223 Embedded Module |
|
KDI offers the broadest selection of ZigBee wireless networking solutions available in the industry. Our 2.4GHz IP-Link Modules support data rates up to 250Kbps. IP-Link Modules can be ordered in your choice of ultra low power to long distance transmit range, along with several standards-based packaged terminals, development kits, design tools and design & integration services to help you complete your global development and deployment project.
POWERFUL DEVELOPMENT ENVIRONMENT
KDI's IP-Link Module Family includes support for the Keil C compiler and integrated development environment, allowing you to port your application directly onto the IP-Link module to reduce software subsystem testing and cost. |
|
| |
|
|
 |
|
| ▲ Appearance of the product |
|
|
|
|
FLEXIBLE ZIGBEE - COMPLIANT NETWORKING SOLUTIONS
IP-Link Modules support mesh, star and hybrid networking topologies and come with KDI's ZigBee-Compliant or IP-Net software. Simply select the Networking solution that best meets your needs for interoperability, IP compatibility, or simplicity. KDI's ZigBee-Compliant IP-Net networking software is ideal for customers looking for a highly reliable and field-proven wireless solution. IP-Net includes support for our innovative 'serial mesh mode', allowing RS232/RS485 data streams to be transmitted over multiple hops to improve data reliability and increase transmission range. Alternatively, KDI also provides a ZigBee-Compliant networking stack library to enable third party product and system integration with existing tracking, locations and security systems. |
|
| Features |
| ► |
2.4GHz standards-based platform support data rates up to 250Kbps |
| ► |
IEEE802.15.4 - Compliant |
| ► |
Industry Standard RS232/RS485 Interface |
| ► |
Low Power Consumption Design, 0dBm Transmit Power |
| ► |
ZigBee-based Networking Supporting Star, Cluster-Tree, and Mesh Topologies |
| ► |
RF Receive Sensitivity -90dBm , 100m LOS Transmit Range |
| ► |
Choice of PCB, or U.FL Antenna |
| ► |
FCC Part15 Certified |
|
|
 |
| |
| Order List |
| Product ID |
Antenna |
Physical Connector |
| IP-Link 1223-5021 |
PCB |
Stamp Hold |
| IP-Link 1223-5022 |
PCB |
Pin Header |
| IP-Link 1223-5041 |
U.FL |
Stamp Hold |
| IP-Link 1223-5042 |
U.FL |
Pin Header |
|
|
|
|
|
|
| |
